Maverick
ANOTHER SMOOTH MOVE IN INNOVATION FIRSTS
We created a mower in a class by itself — a commercial-grade mower with Integrated Drive Systems featuring our patented EZ-Ride® System—at a breakthrough price! With independent front and rear suspension, the Maverick glides over uneven terrain — and through a price point other mower manufacturers thought impossible.
With a lower profile and wider stance, we’ve increased traction and even added our new DeckDial for precise cutting height. Packed with popular high-performance engines—It delivers all the power to bear on whatever you’re mowing.
MOWER SPECIFICATIONS |
|
|---|---|
| Cutting Width | 4800 – 48″; 5400 – 54″; 6000 – 60″ |
| Cutting Height | 1.5″ – 4.5″ with Deck Height Control System |
| Blades | 4800 – 1/4″ x 2 1/2″ x 16 1/2″, High Lift, Heat Treated 5400 – 1/4″ x 2 1/2″ x 18 3/4″, High Lift, Heat Treated 6000 – 1/4″ x 2 1/2″ x 20 1/2″, High Lift, Heat Treated |
| Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 4800 – 4 Total (2 Front, 2 Rear) 5400 – 4 Total (2 Front, 2 Rear) 6000 – 6 Total (4 Front, 2 Rear) |
| Deck Flotation | Floats On Four 1/4″ Deck Hangers |
| Deck Thickness | 3/16″ Thick Solid Steel |
DRIVE SYSTEM SPECIFICATIONS |
|
|---|---|
| Transmission | Hydro-Gear® ZT-3200 Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motor w/Gear Reduction |
| Wheel Drive | Integrated With Commercial Grade Gear Reduction |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | 25 Micron, Replaceable Spin-On Type, 1 Per Pump |
| Pumps | 10cc Pump And Motor Integrated In One Unit |
| Hydraulic Coolers | 7″ RPM Cooling Fan; One per unit |
MOWER DIMENSIONS |
|
|---|---|
| Weight | 4800 – 862 lbs.; 5400 – 871 lbs.; 6000– 925 lbs. |
| Overall Height | 49″ |
| Overall Width Chute Up/Chute Down |
4800 – 54″ / 61″; 5400 – 58″ / 67″; 6000 – 64″ / 76″ |
| Overall Length | 75″ |
| Tire to Tire Width | 46 1/2″ |
| Tires – Front | 13 x 6.5 – 6 Smooth Tread |
| Tires – Rear | 4800 – 23 x 8.5 – 12 Turf Tread; 5400 – 23 x 10.5 – 12 Turf Tread; 6000 – 23 x 10.5 – 12 Turf Tread |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn – Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 9 mph |
| Parking Brake | Internal Parking Brake |
