Revolt
OUR NEW STAND-ON IS A STAND-OUT PERFORMER
The totally redesigned Revolt Stand-On Commercial Zero Turn Mower has been improved in every way and features improved performance, operator ease-of-use and durability. Operator visibility is improved with new, shorter frame and curved iBeam front fork support.
The rear tires are larger and the fuel tank is now located in the center of the machine. This allows the rider to stand directly between both rear tires, resulting in a lower center of gravity and making the Revolt Stand-On Zero Turn Mower one of the most maneuverable — and balanced — Stand-On Mower’s in the industry. So even though we’ve managed to make it smaller, we’ve packed in bigger performance all the way around.
MOWER SPECIFICATIONS |
|
|---|---|
| Cutting Width | 4800 – 48″; 5400 – 54″ |
| Cutting Height | 2″ – 5″ In 1/4″ Increments |
| Blades | 4800 – 1/4″ x 2 1/2″ x 16 1/2″, High Lift, Heat Treated 5400 – 1/4″ x 2 1/2″ x 18 3/4″, High Lift, Heat Treated |
| Lift and Height Adjustment | Manual Quick-Adjust Setting with Hand Lever |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 5400 – 6 Total (4 Double-Bracketed Front Wheels, 2 Rear Wheels) |
| Deck Flotation | Floats On Four 1/4″ Deck Hangers |
| Deck Thickness | 3/16″ Thick Solid Steel With Additonal 1/4″ Steel Leading Edge And 3/8″ Side Trim |
DRIVE SYSTEM SPECIFICATIONS |
|
|---|---|
| Transmission | Industrial Grade Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motor w/Planetary Gear Reduction |
| Wheel Drive | Hydro-Gear® Integrated 3400 Series Transaxle |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | Internal, Replaceable, 1 Per Axle |
| Pumps | – |
| Hydraulic Coolers | 8″ 3,600rpm Cooling Fan; One Per Unit.; 8″ 3,600RPM Cooling Fan; One Per Unit |
MOWER DIMENSIONS |
|
|---|---|
| Weight | 4800 – 905 lbs.; |
| Overall Height | 48″ |
| Overall Width Chute Up/Chute Down |
4800 – 50 1/2″/62 1/2″; 5400 – 56 1/2″ / 68 1/2″ |
| Overall Length | 63″ |
| Tire to Tire Width | 4800 – 43 1/2″; 5400 – 43 1/2″ |
| Tires – Front | 13 x 6.5 – 6 Smooth Tread |
| Tires – Rear | 23 x 9 – 12 Reaper Tires |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn – Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 10 mph |
| Parking Brake | Internal Parking Brake |
