MZ Magnum
DON’T LET THE PRICE FOOL YOU, THESE ARE BUILT-TO-LAST
Most mowers at this price are made from flimsy stamped steel and bolted together. So if you’re looking for the efficiencies of a zero-turn mower at a price that does not compromise on quality construction and quality of cut — turn to the MZ Magnum.
With larger and stronger frames—sporting an even stronger 7-gauge all-steel, fabricated deck — the MZ Magnum is far more substantial in build quality than other mowers in this price range. You’ll immediately appreciate the rock-solid, all-steel welded construction, powerful engine and ‘too much fun to call it work’ ride.
MOWER SPECIFICATIONS |
|
|---|---|
| Cutting Width | 4800 – 48″; 5400 – 54″ |
| Cutting Height | 1.5″ – 4.5″ with Deck Height Control System |
| Blades | 4800 – 7/32″ x 2 1/2″ x 16 1/2″, High Lift, Heat Treated 5400 – 7/32″ x 2 1/2″ x 18 1/2″, High Lift, Heat Treated |
| Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 2 Front |
| Deck Flotation | Floats On Four 1/4″ Deck Hangers |
| Deck Thickness | 3/16″ Thick Solid Steel |
DRIVE SYSTEM SPECIFICATIONS |
|
|---|---|
| Transmission | Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motoro w/Gear Reduction |
| Wheel Drive | Integrated with Gear Reduction |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | – |
| Pumps | EZT Integrated Unit |
| Hydraulic Coolers | 7″ Cooling Fan per Unit |
MOWER DIMENSIONS |
|
|---|---|
| Weight | 4800 – 661 lbs.; 5400 – 686 lbs. |
| Overall Height | 42″ |
| Overall Width Chute Up/Chute Down |
4800 – 54″ / 61″; 5400 – 58″ / 67″ |
| Overall Length | 76″ |
| Tire to Tire Width | 46″ |
| Tires – Front | 11 x 6.0 – 5 Smooth Tread |
| Tires – Rear | 18 x 9.5 – 8 Turf Tread |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn – Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 6 mph |
| Parking Brake | External Cogg Brake |
