XBS Black Strip Tubing
XBS Black Stripe Tubing
High quality, flexible tubing for use in any low-volume irrigation system.
It’s convenient. Produced with a black or with a double vibrant-colored stripe pattern for easy zone identification, the colors add simplicity to maintenance and installation.
- 1/2" and 3/4" blank tubing extruded from polyethylene resin materials for consistent durability.
- 1/2" tubing is now available in two different sizes: 0.600" I.D. X 0.700" O.D. and 0.615" I.D. X 0.705" O.D.
- Available in five color stripe patterns to differentiate zones.
- UV-resistant for installations at or below grade.
- Compact coils for easy storage and shipping.
XBS - 1/2" Tubing Models - (OD: 0.705"; ID: 0.615")
XBS100: 1/2" tubing, 100 foot (30 m) coil with green striping- XBS500: 1/2" tubing, 500 foot (152 m) coil with green striping
XBS100B: 1/2" tubing, 100 foot (30 m) coil with black striping- XBS500B: 1/2" tubing, 500 foot (152 m) coil with black striping
XBS500R: 1/2" tubing, 500 foot (152 m) coil with red striping
XBS500Y: 1/2" tubing, 500 foot (152 m) coil with yellow striping
XBS500P: 1/2" tubing, 500 foot (152 m) coil with purple striping
XBS700 - 1/2" Tubing Models - (OD: 0.700"; ID: 0.600")
- XBS700G100: 1/2" tubing, 100 foot (30 m) coil with green striping
- XBS700G500: 1/2" tubing, 500 foot (152 m) coil with green striping
- XBS700B100: 1/2" tubing, 100 foot (30 m) coil with black striping
- XBS700B500: 1/2" tubing, 500 foot (152 m) coil with black striping
- XBS700P100: 1/2" tubing, 100 foot (30 m) coil with purple striping
- XBS700P500: 1/2" tubing, 500 foot (152 m) coil with purple striping
XBS 940 - 3/4" Tubing Models - (OD: 0.940"; ID: 0.820)
- XBS940G100: 3/4" tubing, 100 foot (30 m) coil with green striping
- XBS940G500: 3/4" tubing, 500 foot (152 m) coil with green striping
- XBS940P100: 3/4" tubing, 100 foot (30 m) coil with purple striping
- XBS940P500: 3/4" tubing, 500 foot (152 m) coil with purple striping
Operating Range
- Pressure: 0 to 60 psi (0 to 4.1 bar)
